Weight :  299g (without cable)

Cable :  Straight 2.0 meters

Interface :  USB Keyboard, RS232, USB virtual COM

Operating Mode :  Hand-Held, Auto-Detection

Programming :  Method Manual (reading configuration barcode)

Indicator :  Beeper, LED





Electrical

Input Voltage :  4.6 – 5.5 ± 0.25VDC

Current :  110 mA (standby); 370 mA (operation)



Performance

Image Size :  1280 x 800 pixels

Field of View :  Horizontal: 64°, vertical: 44°

Scanning :  Angle ±70º, ±70º, ±360º (skew, pitch, roll)

Print Contrast :  20% minimum reflectance difference

Scanning Pattern :  Area Image

Minimum Resolution :  1D (Code 39): 5 mil; 2D (PDF417): 6.7 mil

Decoding Capability :  1D: UPC-A, UPC-E, UPC-E1, EAN-13, EAN-8, ISBN (Bookland EAN), ISSN, Code 39, Code 39 full ASCII, Code 32, Trioptic Code 39, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Codabar (NW7), Code 128, UCC/EAN 128, ISBT 128, Code 93, Code 11 (USD-8), MSI/ Plessey, UK/Plessey, China Post, China Finance, GS1 DataBar (formerly RSS) variants ; 2D: PDF417, MicroPDF417, QR Code, DataMatrix, Han Xin Code, Aztec Code



Environmental

Operating :  Temperature -20ºC to 55ºC / -4ºF to 131ºF (operating); -20ºC to 75ºC / -4ºF to 167ºF (storage)

Humidity : 5% to 95% (non-condensing);

Safety :  EMC: EN55022, EN55024 ⎹ Electrical Safety: EN60950-1

Photo-biological Safety: EN62471:2008 | illumination: 0~100,000 LUX

Sealing – IP50 | Drop Resistance – Multiple 1.5 m (5.0 ft.) drops to concrete
