Feature
- Mini data collector, Convenient and portable
- Wireless working distance can meet general request, 0 to 300 m in open area
- Can store 100,000 barcodes
- Instantly store and bulk transfer mode, Secure to keep the data
- Can conect via 433MHz wireless reciver or bluetooth
- Auto-turn-off at low voltage. Settable standby time, High efficiency and energy saving
- Easy and comfortable operation
Wireless Communications
Modulation : GFSK
Transmission rate : 200Kbps
Power : 10dBm
Transmission Distance : Visual straight line distance 300 meters
Antenna : Built-in spring antenna
Performance Characteristics
Light Source : 650nm Laser
Supported barcode : EAN-8, EAN-13, UPC-A, UPC-E, Code 39, Code 93, Code 128, EAN128, Codaber, Industoal 2 of 5, Interleave 2 of 5, Matrix 2 of 5, MSI etc.
Scanner Type : Bi-directional
Scan rate : 48+/-2 Scan/Second
Scan distance : 10 - 520 mm
Scan width : 20 mm@window, 220mm@200mm
Resolution : 0.10mm (pcs0.9)
Depth of Field : 0-250mm (0.33mm, PCS90%)
Working Way : Triggered or automatic (Continuous mode) Scanning
Physical Characteristics
Memory : 4M (Can store 100,000 barcodes)
Interfaces : Standard configuration mini USB receiver; RS232 and PS2 optional
Current : 96mA (working) 46mA(standby)
Battery : Built-in rechargeable lithium ion battery (3.7V, 1900mAh)
Material : ABS + PC
Dimension : 102 x 46 x 28 mm (Data Collector) 52 x 20 x 10 mm (Receiver)
Weight : 130g (With Battery)
* สินค้ารับประกัน 1 ปี
